Micro USB To DIP Adapter 5pin Female Connector B Type PCB Converter Breadboard USB-01 Switch Board SMT Mother Seat

2 in 1：

Product Introduction:


1.Input Voltage: 3.7V~5.5V
2.Charging Current: 1A(max)
3.Output Current: 1A(max)
4.Output voltage: 5V
5.BAT Discharging Stop Voltage: 2.9V
6.Discharging Efficiency: 85%(input 3.7V output 5V/1A)

Features:


1.Charging and discharging indication
2.Internally installed charging and discharging power MOS
3.Preset 4.2V charging voltage, precision ±1%
4.Max 8uA standby current
5.Integration charging management and discharging management
6.Intelligent temperature control and overtemperature protection
7.Integration output overvoltage protection,short coircuit protection,overload protection
8.Integration overcharging and overdischarging protection
9.Support trickle mode and zero voltage charging

When charging :red light flashing;
Full charged :red light light for a long time.

18650-Module：

Before use, before debugging, the default output is about 9V.
Input voltage 4.5-8V
The output voltage can be continuously adjusted 4.3-27V
(4.3V or more, 27V or less, any voltage can be output, you can adjust the voltage counterclockwise)
Charging voltage 4.2V Charging current is 1A
Discharge current 2A output current to calculate
Output reference maximum current 5V 1.4A , 9V 0.8A, 12V 0.6A
Static current is about 0.5 mA
Overshoot protection Overdischarge protection None (it can be said that there is 2V cut-off boost, but there is still 2V without blocking the output)
Cut-off boost 2V, depending on the situation, whether to add a protection board

For example, VIN+ termination 5V solar panel BAT+ terminal can output 4.2V to 3.7V 18650 battery charging OUT+ terminal can output an adjustable voltage How much you need to adjust
Can be used for multimeters, modified lithium battery charging
