Wire rope sensor 901-10000-420A long stroke analog wire sensor
Compact size, complete type High test accuracy Long-life using Easy installation Passed CE(Certificate of Compliance) Good after-sale service Usage Posi
Need help before you buy?
Call iBuyRobotics for product guidance, compatibility questions, bulk orders, or support.
(855) I-BUY-ROBO (855) 428-9762
- Compact size, complete type
- High test accuracy
- Long-life using
- Easy installation
- Passed CE(Certificate of Compliance)
- Good after-sale service
|
Usage |
Position Sensor |
|
Model Number |
MS601 Series |
|
Output Type |
Analog |
|
Measuring range |
0-2000mm/2m |
|
Sensor Element |
Potentiometer |
|
Stainless Steel |
1.2mm, Not Plastic-coated |
|
Output |
4-20mA |
|
Linearity |
±0.1%FS,±0.25%FS,±0.5%FS |
|
Repeatability |
0.01% |
|
Resolution |
Infinitesimal |
|
Max. Velocity |
3000mm/s |
|
Vibration Frequency |
50HZ |
|
Response Frequency |
2000HZ |
|
Power |
<1w |
|
Working Voltage |
10-30V(built-in),24V,28V(outlay) |
|
Staring Force |
4N |
|
Net Weight |
1440g |
|
Working temp range |
-45℃~+125℃ |
|
Service Life |
>5 Mio;>10 Mio |
|
Anti-vibration |
10HZ-1500HZ; 10G |
|
Cable Length |
2M(standard) |
|
Housing Compent |
Titanium-anodised Aluminium, the coating is a hartanodic oxidation that protects the sensor from corrosion |
|
Protection Class |
IP67 |
